Automation in Action

See how our automation solutions come to life — demos, insights and innovations direct from our team.

Watch a demonstration of Wes-Tech Automation’s new efficient robotic container stacking project! This successful automated process robot system was achieved for a customer in the healthcare industry. The robotic system stacks five containers high at a speed of more than six containers per minute. The containers are then transported on a continuous running conveyor, entering the system open end-down. As they pass through the system, two automated stamping stations print and apply labels—an essential step for tracking and compliance in this industry. The customer verifies the accuracy of all printed data on the container labels. Once the containers reach the robotic arm, a six-axis robot equipped with a vacuum gripper takes over, deftly picking up each container at the end of the first conveyor line. The automated robotic arm then stacks the containers onto a second takeaway conveyor system with ease and precision. Completed stacks are then released via pneumatic gates, ready for their journey to the pack-off station.To maintain the highest standards of safety and quality control, this automated robotic stacking system include a reject drop-off point. If a container is missing a label or the label is unreadable, it’s automatically diverted to the rejection point located within the robot cell. This quality assurance ensures that only compliant products make it through the automated system.In the healthcare industry, safety is paramount. This automated robotics system incorporates a perimeter of safety guard switch to product both the human operator and automated equipment that makes this stacking system successful.To learn more about Wes-Tech’s innovation automation solutions across all industries, visit our website: https://wes-tech.com/robotics/Ready to move forward with factory automation? Reach out for a free consultation: https://wes-tech.com/contact-wes-tech-for-a-free-consultation/ Connect with Wes-Tech: Website: https://wes-tech.com/ LinkedIn: https://www.linkedin.com/company/wes-tech-automation-solutions Facebook: https://www.facebook.com/Wes-Tech-Automation-Solutions-LLC-188585101209663/
Automated Robotic Stacking System in the Healthcare Industry | Wes-Tech Automation
Wes-Tech successfully addressed the complex requirements of a car seat manufacturer by developing a flexible subassembly lean cell capable of handling multiple part types, including left and right-hand variants, on parallel lanes to produce power car seat H-frames.This video demo showcases the first of three stations involved in the H-frame assembly process. The initial station simultaneously assembles left and right rails. The process includes positioning gearboxes on spindles, applying grease, installing washers and nuts, and riveting the spindle to the rail.Key Steps in the Automated Assembly Process: 1. Component Loading: An operator loads spindles, gearboxes, washers, and nuts. 2. Greasing: Grease is applied to the spindles. 3. Gearbox Positioning: Servo drives position gearboxes on spindles and orients them for subsequent assembly. 4. Nut Installation: Nut-runners drive nuts onto spindles, and crimpers secure them in place. 5. Insertion and Riveting: The spindle/gearbox assembly is inserted into the rail slide, clamped, and riveted. 6. Poka-Yoke: Rubber grommets and pin features are verified for correct installation.Station #2, not shown in this video, is dedicated to motor bracket assembly, which involves attaching a drive motor to a bracket stamping and ensuring all components are correctly installed and error-proofed. Station #3, also not shown, completes the final H-frame assembly by attaching the drive motor bracket to the right and left rail assemblies, securing screws and nuts, and ensuring all components are correctly installed.Our deep understanding of our customer’s needs—beyond technical specifications—enables us to provide them with enhanced flexibility and control when manufacturing this critical component in car seats.To learn more about Wes-Tech’s solutions for complex manufacturing challenges, visit our website: https://wes-tech.com/capabilities/. Reach out today to learn what we can do for you.#automotive #carseats #engineering #manufacturing #ingenuity #automation
Power Seat H-Frame Assembly | Wes-Tech Automation Solutions
At Wes-Tech, we understand that installing insulation as part of a power generator assembly can be both complex and hazardous. Our customer faced challenges with manual insulation installation, which required multiple operators and potentially exposed workers to toxic adhesive fumes and hazardous heat lamps.To mitigate these risks, we developed an automated system that significantly reduces human involvement. The process begins with a single operator applying a gasket to a hood substructure and cycling the part on a rotary table to the next assembly station.A Fanuc robot then takes over, retrieving hood covers from incoming dunnage and accurately positioning each cover for adhesive application. The adhesive is applied by a metered dispensing head, after which the robot places the cover onto a conveyor. The previously gasketed substructure is then placed into the cover.In the manual process, workers had to place these half-assembled hoods into ovens with heat lamps to cure the adhesive, which released toxic fumes. Our automated system accelerates the adhesive bonding time while the hoods are conveyed to the next assembly station. The conveyor features three integrated curing stations, where heat and pressure are applied at three different intervals during transit.Upon reaching the final station, the hoods are ready for the final pieces of insulation, which have undergone automated adhesive application, to be attached by another Fanuc robot.Wes-Tech’s automation solutions solve complex manufacturing challenges, mitigating risk to your workforce, production downtime, and productivity roadblocks. To learn more about what Wes-Tech can do for you, visit our website: https://wes-tech.com/capabilities/#powergenerator #manufacturing #automation #assembly #ingenuity
Automated Power Generator Hood Assembly | Wes-Tech Automation Solutions
Wes-Tech’s in-line panel clinching semi-automatic system efficiently and precisely uses TOX® clinching technology to attach clips to an appliance panel.In this project, Wes-Tech devised a system for datum-izing, crowding, and squaring various sizes of sheet metal panels so that clips could be secured to the metal in precisely the right location every time.With this system, vacuum gripping heads accurately place an incomplete panel onto a fixture that locates the precise position of the clip, ensuring repeatability and consistency.This repeatable and consistent automation eliminates the potential for wasted parts due to inaccurate clip placement, which, in turn, means tremendous cost savings for our customer. The precision of Wes-Tech's clip-clinching system creates higher-quality products for our customer, giving them an edge in their marketplace.The system uses just one operator to manage a clip feeder bowl, maintain optimal lubricant levels, and position panels on an infeed conveyor.Discover more about Wes-Tech’s automation solutions here: https://wes-tech.com/complex-manufacturing-challenges/#manufacturing #manufacturingautomation #consumergoods #ingenuity
Wes-Tech Panel Clinching In-Line Automation
This 7-speed automatic transmission assembly is a marvel of engineering, comprised of over 400 individual parts and weighing a substantial 165 kg (364 lbs.). The core of the assembly solution is a set of four off-line press stations, each capable of exerting between 60-100 kN (13,500-22,500 lbs.) of force, equipped with servo-actuated positioning tables and CNC-style automatic tool changers for precision and efficiency.A key feature of the Wes-Tech transmission assembly system is a low-profile conveyor system that uses independently powered pallets. These pallets are designed with the capability to perform servo lift and rotate functions, thereby positioning parts accurately for either manual or automatic operations. The conveyor's individual pallets lift, rotate, and reposition components at each station along the production line, ensuring seamless transitions and handling.The gear shafts, including the main shaft and countershaft, are handled by a double-dial Promess® machine. Operators engage with this machine by loading parts onto the lower dial, and press tools are selected from the upper dial—akin to a change-tool turret, which then rotates to the pressing position. After the parts are pressed together, the dial rotates back, allowing the operator to load the next set of components. This efficient design means that all gear shafts for the transmission are pressed at a single station.Wes-Tech’s customer initially proposed a system with 12 different servo press stations, which resulted in low utilization and productivity, with cycle times of one part every 10 minutes. However, the team achieved significant improvements by integrating operations into the 4 servo semi-automatic press stations. Not only was the customer able to reduce the cycle time dramatically, but they also managed to decrease headcount and the number of press stations required, leading to a more streamlined and cost-effective production process.#transmissionassembly, #automation #automatictransmissionassembly, #manufacturing, #automotivemanufacturing, #automotivesolutions
From Parts to Performance: 7-Speed Automatic Transmission Assembly Demo from Wes-Tech
Attention water pump manufacturers! Check this out. This video shows a flexible indexing solution that accommodates a high mix, high variety, and high volume of products while performing rapid single-part changeover. Thanks to this design for manufacturability and automated assembly—which enabled this semi-automated machine to work with the universal features of water pump components—our customer has the advantage of adding new product types to production at jaw-droppingly low costs.We helped this customer transform their business model with nine custom water pump assembly machines, each automating differently based on variable inputs. These assembly machines were built to handle dozens of SKUs with quick-change tooling.Throughout our nearly fifty-year history, Wes-Tech has delivered fully automated water pump assembly machines and lean cells for our customers, taking into account the needs of each situation, such as throughput, operators, and quality requirements.Learn more about Design for Automated Assembly here: https://wes-tech.com/dfaa-strategies-optimizing-product-design-for-automated-assembly-success/. If you’re ready to begin your next water pump assembly project, contact Wes-Tech today! https://wes-tech.com/contact-wes-tech-for-a-free-consultation/#ingenuity #manufacturing #waterpump #automation
Wes-Tech Semi Automated Water Pump Assembly on a Dial Indexer
Sparks are flying in this video, but that's not even the most exciting part! We skyrocketed the quality of our customer's products thanks to this welding cell's precision and consistency in squaring consumer storage units. This machine crowds, clamps, and squares to the perfect geometry of multiple SKUs. It's an entirely flexible, dynamic, single-part flow, high-mix, high-variety cell that can accommodate and adjust to many sheet metal sizes. Moreover, this automated welding cell eliminates the need for our customers to work in "batch mode." Built-in automatic tooling means zero-time changeover and easy maintenance.With this squaring and spot-welding project, we applied an automotive body-in-white concept to durable consumer goods. We have retooled this machine several times to accommodate an even wider variety of SKUs than it was originally designed for.Ready for a spark of inspiration to begin your next squaring-and-welding project? Read about robotics at Wes-Tech here: https://wes-tech.com/robotics/.#ingenuity #automation #robotics #consumergoods #welding
Wes-Tech Robotic Squaring and Welding Cell
Wes-Tech’s extraordinary automation solutions are far-reaching! Watch never-before-seen footage of our panel clinching in-line automation, which uses a TOX® clinching process to attach brackets to a dishwasher panel.Also shown are snippets of our seven-speed, dual-clutch automatic transmission assembly system. This transmission—suitable for trucks and buses—consists of over 400 parts, which, when all assembled, total more than 360 pounds. The key takeaway? Wes-Tech's automation solutions can handle heavy parts!This video also features our high-speed compressor pump assembly line, which replaced four manual assembly lines. Learn more about this Wes-Tech project here: https://www.youtube.com/watch?v=bWbnHJ7bd2QFinally, you'll see our fully automated differential case assembly and test, which replaced two manual assembly cells in a plant that needed to accommodate the demand for increased volume. You can learn more about this project here: https://www.youtube.com/watch?v=4ayL6YPYnCUWes-Tech tackles complex manufacturing challenges with a current track record of 99%+ on-time delivery for the last 15 years. Learn more about what Wes-Tech can do for you: https://wes-tech.com/complex-manufacturing-challenges/#Automation #Manufacturing #Ingenuity #Automotive #ConsumerGoods #Engineering
Extraordinary Automation Solutions from Wes-Tech
Wes-Tech’s Precision Link Assembly and Test is a high-speed line that can assemble motor/pump units for pancake style 5-gallon air compressors in just 5.6 seconds per part. This innovative solution replaces four manual assembly cells in the plant, reducing the headcount from 12 operators per shift to 5 per shift. The line performs various assembly processes, such as auto drive screws, press bearings, fan and pulleys with force and distance monitoring, and time and tension drive belt. The parts are infeed from different sources, such as manual loaded belt conveyors, magazine stacks, and vibratory feeder bowl. The result is a fast, efficient, and reliable assembly line that meets the highest quality standards.Learn more about our assembly and test capabilities here: https://wes-tech.com/complex-manufacturing-challenges/. We strive to be on the cutting edge of innovative automation solutions. Ready to see what Wes-Tech can do for you? Check us out: https://wes-tech.com/about-us/.#ingenuity #assembly #manufacturing #robotics #automation
Wes-Tech Precision Link Assembly and Test
This Wes-Tech Knuckle Assembly System, designed for an automotive customer, assembles and validates a high volume of mirror-image (left-hand/right-hand) parts. The assembly system uses a combination of shuttles, conveyors, and Fanuc robots to move parts through the multi-step process, which includes probe-checking, identification pin-stamping, a bushing press, and a press-out test. A collaborative robot (cobot) uses vision guidance to pick and load bushings to a buffer chute. The Wes-Tech Knuckle Assembly system produces one knuckle every 17.5 seconds.In addition to reduced labor costs, our customer has found immense value in the assembly-process data that is now associated with each part, thanks to serialized pin-stamping with sequential ID numbers. Our customer has also enjoyed enhanced quality due to QA mechanisms built in throughout the assembly process.Interested in learning more about Wes-Tech's assembly and test capabilities? Check us out: https://wes-tech.com/complex-manufacturing-challenges/#automotive #robotics #cobot #automation #ingenuity
Wes-Tech Automotive Knuckle Assembly System
Wes-Tech’s Differential Case Assembly and Test project involved designing and building a high-speed line to assemble and test rear differential covers for vehicles. The line can produce one part every 15.7 seconds, replacing two manual assembly cells in the plant and meeting increased demand. The assembly processes include:• Machined feature verification (thread check). • Auto feed and drive plugs and pressure sensor to torque. • Differential pressure decay leak testing for high- and low-pressure circuits within the cover. • Auto feed and install bearing to cover. • Auto feed and install filter with snap ring to cover, with vision verification. • Auto feed, vision check O-rings, lube and piston to cover. • Auto feed and install piston retainer, spring and snap ring to cover, with vision verification. • Auto feed, lube and install solenoid valve to cover. • Auto feed and drive solenoid retaining screw to torque.To learn more, visit https://wes-tech.com/robotics/. We strive to be on the cutting edge of innovative automation solutions. Ready to see what Wes-Tech can do for you? Check us out: https://wes-tech.com/about-us/.#ingenuity #automotive #manufacturing #diecasting
Wes-Tech Differential Case Assembly and Test
Tech-Trak® Pallet Conveyors are a standard product offered by Wes-Tech. Tech-Trak’s single-strand, modular palletized design is a game-changer for discrete manufacturers. Its many innovative features include:• Efficiency in Asynchronous Processing: Tech-Trak’s single-strand design allows independent unit handling and routing, maximizing overall efficiency and throughput. • Flexibility and Scalability: The modular palletized design is scalable and reconfigurable to accommodate evolving production demands. • Single Strand Durability in Harsh Environments: The single-strand design is built to withstand extreme manufacturing environments, including vibration, temperature fluctuations, and abrasive materials, reducing maintenance costs and production downtime.Tech-Trak offers two series of palletized designs to cater to different manufacturing needs:• 1700 Medium Series: This series has a pallet capacity of 80lb max (pallet, part, and fixture) and a maximum of 600 lb. total combined pallet, part, and tooling accumulated on any section of chain. • 2500 Heavy Duty Series: This series has a pallet capacity of 300lb max (pallet, part, and fixture) and a maximum of 2000lb total pallet, part, and tooling accumulated on any section of chain.To learn more, visit https://wes-tech.com/conveyor-systems/. We strive to be on the cutting edge of innovative automation solutions. Ready to see what Wes-Tech can do for you? Check us out: https://wes-tech.com/about-us/.#ingenuity #conveyorsystems #manufacturing #materialhandling
Tech-Trak Pallet Conveyors
The Wes-Tech TCL Gantry material handling robot is a standard Wes-Tech product. In this video, you’ll see one of our gantries in action as part of a machining line automation solution for producing differential carriers.Our machining line automation here handles part weights up to 105 lbs. each and achieves a remarkable cycle time of 57 sec/part. The automation solution consists of four main components:• A Tech-Trak 2500 series conveyor for parts infeed • A TCL27 Series Dual Carriage Gantry, 136 feet long, that spans over eight CNC machines • An integration to a parts washer • A robot that tends the gauge station and transfers the parts to the outfeed conveyorTo learn more, visit https://wes-tech.com/automated-transfer-processes/. Ready to see what Wes-Tech can do for you?#ingenuity #automotive #gantry #robotics #manufacturing #materialhandling
Wes-Tech TCL Gantry Series
Tech-Trak® Pallet Conveyors and TCL Gantry material handling robots are two standard products offered by Wes-Tech.Tech-Trak Pallet Conveyors ensure smooth and efficient movement of palletized loads. They can be tailored to specific load sizes, weights, and production requirements. Features include advanced control systems, including PLC/RFID integration, enabling precise tracking, sorting, and routing of palletized loads.Significantly, they integrate with other automated systems, such as robotic arms, gantry systems, and automated storage solutions. They are designed for durability, especially in harsh manufacturing environments, ensuring long-lasting performance and reliable operation.Learn about our material handling capabilities here: https://wes-tech.com/automated-transfer-processes/ and find Tech-Trak details here: https://wes-tech.com/conveyor-systems/#ingenuity #conveyorsystems #gantry #robotics #manufacturing #materialhandling
Material Handling and Discrete Manufacturing: Tech-Trak Conveyors, Gantries, and Robotics
